Verified fitment — 2 vehicles
Fitment is sourced from official parts catalogues, listed per catalogue market.
China (2)
Location in exploded diagrams
Other parts on this diagram — 未分组
- #1 350017-P300-00000 — 后轮胎
- #4.1 352500-P303-B0200 — 后铝轮总成
- #4.2 352500-P303-R0700 — 后铝轮总成
- #4.3 352500-P303-C0100 — 后铝轮总成
- #5 5011-00200-SC00 — 钢丝卡
- #6 5010-38150-YH01 — 后轮轴螺母
- #7 5018-39010-SC00 — 平垫
- #8 910002-R201-000 — 后轮衬套-左
- #10 410003-P200-00000 — 后轮轴
- #11.1 910003-R201-00001 — 后轮衬套-右
- #11.2 910003-R201-000 — 后轮衬套-右
- #2 5020-76015-BS00 — 挡圈
- #3 420035-R201-001 — O型胶圈
- #4 5020-62015-HX00 — 弹性挡圈
- #5 5101-406212-BS0 — 轴承
- #6 370021-R201-000 — 偏心轮
- #7 5102-506225-BS0 — 滚针轴承
- #8 5020-75025-HX00 — 弹性挡圈
