Verified fitment — 1 vehicle
Fitment is sourced from official parts catalogues, listed per catalogue market.
China (1)
Location in exploded diagrams
Other parts on this diagram — 护罩组
- #1 48111H7W000H845 — 前斜板(哑光星际灰)
- #1 48111H7W000H501 — 前斜板(珍珠黑)
- #2 48137H7W000H901 — 前下护罩(珍珠白)
- #2 48137H7W000H501 — 前下护罩(珍珠黑)
- #3 48139H7W000H000 — 底盖
- #4 48138H86100H000 — 底盖保护盖
- #5 48142H7W000H129 — 前下护罩右装饰盖(炫酷红)
- #5 48142H7W000H216 — 前下护罩右装饰盖(火焰橙)
- #5 48142H7W000H626 — 前下护罩右装饰盖(天湖蓝)
- #5 48142H7W000H501 — 前下护罩右装饰盖(珍珠黑)
- #6 92171-32G00-000 — 前货箱体挂钩
- #7 01550-0616B-000 — 六角法兰面螺栓
- #8 48236H7W000H000 — 前下护罩右挡板
- #9 48237H7W000H000 — 前下护罩左挡板
- #10 48242H7W000H129 — 前下护罩左装饰盖(炫酷红)
- #10 48242H7W000H216 — 前下护罩左装饰盖(火焰橙)
- #10 48242H7W000H626 — 前下护罩左装饰盖(天湖蓝)
- #10 48242H7W000H501 — 前下护罩左装饰盖(珍珠黑)
- #11 09148-05L08-000 — 锁片螺母
- #12 09148-05077-000 — 锁片螺母
- #13 92125-33GC0-000 — 前货箱盖内衬板安装螺钉
- #14 03241-0516B-000 — 十字槽自攻螺钉
- #15 01550-0612A-000 — 六角法兰面螺栓
- #16 09136H04003H000 — 平垫螺钉组合
