Verified fitment — 3 vehicles
Fitment is sourced from official parts catalogues, listed per catalogue market.
Location in exploded diagrams
Other parts on this diagram — 未分组
- #1 350001-R100-00006 — 过油螺栓
- #2 350002-R100-000 — 铜垫圈
- #3 350800-P300-00000 — 制动油管1
- #4 350900-P303-00000 — 制动油管2
- #5 5001-06010-SC00 — 六角法兰面螺栓
- #6 350001-R100-00007 — 过油螺栓
- #7 351300-P303-00000 — ABS总成
- #8 350001-P303-00000 — 过油螺栓
- #9 350301-P303-00000
- #10 350300-P303-00000 — 前制动卡钳总成-左
- #11 351100-P200-00000 — 制动油管4
- #12 351000-P300-00000 — 制动油管3
- #13 5001-06016-SC00 — 六角法兰面螺栓
- #14 400006-P200-E0100 — 线钩
- #15 5005-06012-SC00 — 十字半圆头螺钉
- #16 350700-R100-000 — 后制动开关
- #18 352200-R100-000 — 后制动杆端轴承
- #19 350500-R203-00001 — 后制动卡钳总成
- #20 350501-R201-00001
- #21 350303-P303-00000 — 排气螺钉胶帽
