Verified fitment — 1 vehicle
Fitment is sourced from official parts catalogues, listed per catalogue market.
China (1)
Location in exploded diagrams
Other parts on this diagram — 停车架组
- #1 42100H2J000H000 — 主停车架组成
- #2 42241H2J000H000 — 主停车架弹簧Ⅰ
- #3 42242H2J001H000 — 主停车架弹簧Ⅱ
- #4 42272-09J00-000 — 主停车架减震垫
- #5 09111H10008H000 — 轴肩螺栓
- #6 08319-3110A-000 — U型螺母
- #7 42310H2J001H000 — 侧支架组成
- #8 42421H2J000H000 — 侧支架弹簧
- #9 09111H10060H000 — 轴肩螺栓
- #11 43110H2J000H000 — 制动踏板组成
- #13 09443H06005H000 — 拉伸弹簧
- #14 08322-0114A-000 — 平垫圈
- #15 04111-3025A-000 — 开口销
