Verified fitment — 7 vehicles
Fitment is sourced from official parts catalogues, listed per catalogue market.
Location in exploded diagrams
Other parts on this diagram — 车把组合
- #17 09209C11002W000 — PIN (11X18)
- #18 09150C06010W000 — NUT
- #19 58575C39J00W000 — PLATE, REAR BRAKE CABLE
- #20 01547C0610AW000 — BOLT
- #21 58577C33G00W000 — CLAMP, RR BK CABLE FRONT
- #23 03541C0516AW000 — SCREW
- #24 02142-0510A-000 — SCREW
- #25 02142-0510B-000 — SCREW
- #1 56110C10K00W000 — HANDLEBAR
- #2 51358C09G50W000 — STOPPER, HANDLEBAR
- #3 56278-40J00-000 — BALANCER
- #4 02122-0640B-000 — SCREW
- #5 09106C10091W000 — BOLT (10X48)
- #6 08319C3110AW000 — NUT, HANDLE BAR
- #7 56500Q10K20W000 — MIRROR ASSY, REAR VIEW RH
- #8 56600Q10K20W000 — MIRROR ASSY, REAR VIEW LH
- #9 58300C10K00W000 — CABLE ASSY, THROTTLE NO.1
- #10 58300C45K00W000 — CABLE ASSY, THROTTLE NO.2
- #11 58510C10K00W000 — CABLE, REAR BRAKE
- #12 58562C09J00W000 — SPRING, REAR BRAKE CABLE
- #13 58620C10K10W000 — GUIDE, FRONT BRAKE CABLE
- #14 58630-10K00-000 — GUIDE, CABLE
- #15 09407C23402W000 — CLAMP (L:235)
- #26 58110C10K00W000 — CABLE COMP,FRONT BRAKE
