Verified fitment — 1 vehicle
Fitment is sourced from official parts catalogues, listed per catalogue market.
United Kingdom (1)
Location in exploded diagrams
Other parts on this diagram — Cvt Air Pipe & Side Cover
- #12 9010-000105 — A-Type Screw Clamp 78-101
- #04 9AWV-002002-8000 — Joint, Cvt Air Inlet Pipe
- #03 5BWV-040008-5000 — Inner Hex Bolt M6X20 M6X20
- #15 9060-040310 — Clamp Assy
- #19 9030-000109 — Screw Clamp, A-Type 70~90
- #05 9AYV-008010-8500 — Air Filter Rh Intake Pipe Connector
- #13 5ASV-000105-6000 — Clamp
- #22 0180-015003 — Rubber Sleeve
- #10 5BWV-040016-5000 — Inner Hex Slef-Tapping Screw St4.8X16 St4.8X16
- #06 9AYV-048009-8502 — Cvt Intake Pipe
- #09 9AWV-044052-8000 — Cap, Oil Filler
- #13 9AWV-042041-8000 — Lh Side Cover, Engine
- #22 9AYV-008012-8500 — Cvt Air Outlet Pipe 2
- #11 5020-031001 — Rubber Sleeve, Front License Bracket
- #01 9AYV-008021-8500 — Intake Port
- #07 9AYV-008019-8501 — Cvt Intake Pipe Connector
- #15 5BYV-041089-A100 — Cvt Inlet Port Seal Sponge Strap
- #06 9AWV-000305-8000 — Joint, Air Outlet Pipe
- #23 9AYV-008013-8500 — Cvt Air Inlet Pipe Connector
- #02 8080-041130 — Expansion Rivet Assy
- #02 30604-301300 — Clamp
- #14 TFQ004 — Heat Insulation Scroll Paper 50X0.062M
- #20 9AYV-008011-8501 — Cvt Air Outlet Pipe 1
- #19 5BY0-040010 — Rubber Sleeve
