Location in exploded diagrams
Other parts on this diagram — 未分组
- #1 390030-R100-000 — 油箱下护板-左 500GY、黑色皮纹PP料,带防震棉状态 件
- #2 5004-05013-BS00 — 内六角台阶螺钉M5*13 件
- #4 5006-04013-HX00 — 自攻螺钉T头ST4.2*13 件
- #7 5001-06020-SC00 — 六角法兰面螺栓M6*20 件
- #8 390031-R100-000 — 油箱下护板-右 500GY、黑色皮纹PP料,带防震棉状态 件
- #9 390038-R100-A00 — 油箱下护板装饰件-左 500GY、亚光银白色，材料ABS 件
- #10 390039-R100-A00 — 油箱下护板装饰件-右 500GY、亚光银白色，材料ABS 件
