Verified fitment — 1 vehicle
Fitment is sourced from official parts catalogues, listed per catalogue market.
China (1)
Location in exploded diagrams
Other parts on this diagram — 后挡泥板组
- #1 63112H7N000H000 — 后挡泥板下体
- #2 01550-0616B-000 — 六角法兰面螺栓
- #3 09169-06071-000 — 后牌照衬垫
- #4 09180H06026H000 — 衬套
- #5 09320H08007H000 — 减震垫
- #6 09116-06167-000 — 平垫螺栓组合
- #7 63111H7N001H000 — 后挡泥板
- #8 41244H7N000HN00 — 右尾板组成
- #9 41245H7N000HN00 — 左尾板组成
- #10 01550-0612A-000 — 六角法兰面螺栓
- #12 09160-06013-000 — 防护支架垫圈
- #13 08316-1006B-000 — 六角法兰面螺母
- #14 09800H20015H000 — 随车工具总成
- #15 53145-48B00-000 — 燃油箱减震垫Ⅰ
