Verified fitment — 1 vehicle
Fitment is sourced from official parts catalogues, listed per catalogue market.
China (1)
Location in exploded diagrams
Other parts on this diagram — FRONT CALIPER................. 67
- #1 59100C29J10W000 — CALIPER ASSY LH
- #2 55156C29J00W000 — .CAP, BLEEDER
- #3 59121C29J00W000 — .BLEEDER
- #5 59304C29J00W000 — .PISTON CALIPER
- #6 59108C29J00W000 — .DUST SEAL
- #7 59107C29J00W000 — .SEAL,PISTON
- #8 59300C29880W000 — .PAD SET
- #9 59305C29J00W000 — .BOLT, PIN
- #10 59306C29J00W000 — .BOLT, PIN
- #11 59308C29J00W000 — .GASKET
- #12 59312C29J00W000 — .BOOT, PIN BUSH
- #13 59313C13001W000 — .PROTECTOR, CALIPER
- #14 59313C29J00W000 — .BOOT
- #15 59315C29J00W000 — .SPRING, PAD
- #16 59351C29J00W000 — .BRACKET
- #17 59355C29J00W000 — .NUT
- #18 69141C29J00W000 — .PIN, HANGER
- #19 02112C7512BW000 — .SCREW
- #20 01550C0835AW000 — BOLT
