Verified fitment — 1 vehicle
Fitment is sourced from official parts catalogues, listed per catalogue market.
United Kingdom (1)
Location in exploded diagrams
Other parts on this diagram — Front Fender And Speedometer
- 53013155 — MGB ATX 125 FENDER, FRONT
- 73010907 — MGB ATX 125 GROMMET, HEADLIGHT
- 70120148 — MGB ATX 125 COLLAR, 6x8mm
- 74030295 — MGB ATX 125 STICKER, FR. UPPER FENDER
- 53013294 — MGB ATX 125 FENDER, FR. UPPER (RED)
- 53013293 — MGB ATX 125 FENDER, FR. UPPER (ORANGE)
- 53013292 — MGB ATX 125 FENDER, FR. UPPER (BLUE)
- 53013291 — MGB ATX 125 FENDER, FR. UPPER (BLACK)
- 72160004 — MGB ATX 125 NUT, U CLIP, M6, 20x11-10
- 72010236 — MGB ATX 125 BOLT, FLANGE, M6x12
- 73032225 — MGB ATX 125 BRACKET, FR. FENDER
- 72010160 — MGB ATX 125 BOLT, FLANGE, M6x20
- 72030093 — MGB ATX 125 SCREW, M6x16
- 53012491 — MGB ATX 125 FENDER, FR. UNDER
- 32020210 — MGB ATX 125 WINKER ASS'Y, R.FR.
- 32010472 — MGB ATX 125 LIGHT ASS'Y, HEAD
- 53111786 — MGB ATX 125 HOUSING, HEADLIGHT
- 72160009 — MGB ATX 125 NUT, U CLIP, M5, 17x11-10
- 73210285 — MGB ATX 125 BRACKET, HEADLIGHT
- 70120142 — MGB ATX 125 COLLAR, 8.5x22x12
- 73012481 — MGB ATX 125 GROMMET, HEADLIGHT, 11.5x14.5x20.5x9
- 32030210 — MGB ATX 125 WINKER ASS'Y, L.FR.
- 73010800 — MGB ATX 125 RUBBER, NUBER PLATE
- 72030790 — MGB ATX 125 SCREW, SOCKET, M8x25
