Location in exploded diagrams
Other parts on this diagram — 油箱总成 FUEL TANK ASSY.
- #2 B0280050300A — 内六角螺钉M5×30
- #3 B0280050140A — 内六角螺钉M5×14
- #5 52018J800000 — 后货架螺钉I
- #6 B0284060150A — 螺钉M6×15.2/
- #9 50808P250010 — 油位传感器密封圈
- #11 B0109050166H — 螺栓M5×16
- #12 B1701010500H — 钢丝卡箍Φ10.5
- #13 50070P620000 — 油管组件I
- #15 50340N070000 — 滤清器组件
- #16 50376S010000 — 卡箍Φ10
- #18 05533P620000 — 油箱水晶标贴I
- #19 05534P620000 — 油箱水晶标贴II
- #20 50391N070010 — 过滤器护套
- #21 50005P250000 — 油箱前安装垫
- #23 50023L420000 — 油箱海绵垫
- #1 50100P62001Z — 油箱体组件
- #1 50100P62002Z — 油箱体组件
- #1 50100P62003Z — 油箱体组件
- #1 50100P62004Z — 油箱体组件
- #1 50100P62005Z — 油箱体组件
- #1 50100P62006Z — 油箱体组件
- #1 50100P62007Z — 油箱体组件
- #4 50014P250010 — 橡胶垫衬管
- #7 50030P620000 — 油箱前安装板焊接组件
