Verified fitment — 1 vehicle
Fitment is sourced from official parts catalogues, listed per catalogue market.
China (1)
Location in exploded diagrams
Other parts on this diagram — 车体盖组
- #1 47111H2K000H511 — 右侧盖(哑光黑)
- #2 47211H2K000H511 — 左侧盖
- #3 47112H2K000H511 — 右侧罩装饰盖(哑光黑)
- #4 47212H2K000H511 — 左侧罩装饰盖(哑光黑)
- #5 47121H2K000H511 — 右下侧盖(哑光黑)
- #7 92125-33GC0-000 — 前货箱盖内衬板安装螺钉
- #8 09320H06004H000 — 减震垫
- #9 47312H02100H000 — 侧盖橡胶垫
- #10 03241-0512B-000 — 十字槽自攻螺钉
- #11 09148-05077-000 — 锁片螺母
- #12 47214H2K010H000 — 防尘塞
- #13 45515H2H000H000 — 尾罩减震垫
- #14 09139H06024H000 — 特殊形状螺钉
- #15 09320-08513-000 — 减震垫
- #16 09320H06006H000 — 减震垫
- #17 68462H7J100H000 — 排放标签
