Location in exploded diagrams
Other parts on this diagram
- #1.2 390030-P320-R0700 — 油箱下护板-左(KY350GS-2、R07中国红)>白/红/黑
- #2 5006-04013-HX00 — 自攻钉(ST4.2*13)
- #3 390090-P320-00000 — 挡风罩格栅-左(ZF350GS-2)
- #4 390091-P320-00000 — 挡风罩格栅-右(ZF350GS-2)
- #5.1 390031-P320-B1900 — 油箱下护板-右(KY350GS-2、B19珍珠玛瑙黑,贴花编码ZFP303)>红/
- #6 5018-08007-BS00 — 平垫(450Rally、
- #7 5025-05013-BS00 — 内六角花形盘头台阶螺钉(M5*1*13;台阶
- #1.1 360100-P320-00000 — 前座垫总成(ZF350GS-2)>红/绿/黑
- #1.2 360100-P320-00001 — 前座垫总成(KY350GS-2)>白/红/黑
- #2 5013-06008-SC01 — 翻边衬套(
- #3 5025-06020-XN01 — 内六角花形盘头螺钉(M6*20)
- #4 421000-R100-000 — 膨胀胶钉(500GY、长17.5,直径
- #5 390094-P320-00000 — 座垫装饰板(ZF350GS-2)
- #6 360078-P320-00000 — 后座垫拉带(ZF350GS-2)
- #7 5018-06015-SC00 — 平垫(
- #8 5025-06016-XN01 — 内六角花形盘头螺钉(M6*16,盘头14)
- #9 360200-P320-00000 — 后座垫总成(ZF350GS-2)
- #10 400300-R100-00001 — 随车工具(L=82+30mm,L型内六花一端T30，
