Verified fitment — 1 vehicle
Fitment is sourced from official parts catalogues, listed per catalogue market.
China (1)
Location in exploded diagrams
Other parts on this diagram
- #1 5009-05070-DK00 — 螺纹夹板(M5*1.0*7*14)
- #2.1 390024-P320-R0700 — 油箱侧护板-左(KY350GS-2、R07中国红)>红/绿/黑
- #2.2 390024-P320-W0100 — 油箱侧护板-左(KY350GS-2、W01珍珠白)>白/红/黑
- #3 5009-04040-DK00 — 自攻钉夹板(ST4.8*1.6*4*12.5)
- #4 5006-04015-HX00 — 自攻钉(ST4.8*15)
- #5 420008-R201-001 — 工字胶圈(500F、1.5+2.5+1.5)
- #6.1 390035-P320-H2300 — 油箱中护板(KY350GS-2、H23金属灰2代)>白/红/黑
- #6.2 390035-P320-R0700 — 油箱中护板(KY350GS-2、R07中国红)>红/绿/黑
- #7.2 390025-P320-W0100 — 油箱侧护板-右(KY350GS-2、W01珍珠白)>白/红/黑
- #8 420008-R100-000 — 工字胶圈(500GY、
- #9 5013-06008-SC01 — 翻边衬套(
- #10 5025-06020-XN01 — 内六角花形盘头螺钉(M6*20)
- #11 5025-06012-XN01 — 内六角花形盘头螺钉(M6*12,盘头14)
- #1.1 490005-P320-R0700 — 定风翼-左(KY350GS-2、R07中国红)>红/绿/黑
- #1.2 490005-P320-W0100 — 定风翼-左(KY350GS-2、W01珍珠白,贴花编码ZFP305)>白/红/黑
- #3 5025-05016-XN01 — 内六角花形盘头台阶螺钉(M5*1*16,台阶∮8.5*5.5)
- #4 5018-08007-BS00 — 平垫(450Rally、
- #5 5025-05013-BS00 — 内六角花形盘头台阶螺钉(M5*1*13;台阶
- #6.1 490077-P320-B1900 — 挡风罩装饰件-左(KY350GS-2、B19珍珠玛瑙黑)>红/绿/黑
- #6.2 490077-P320-R0700 — 挡风罩装饰件-左(KY350GS-2、R07中国红)>白/红/黑
