2812AL3A000Sym CRUiSYM 300 E5 ONE WAY CLUTCH ASSY — Genuine Sym Part

Verified fitment — 2 vehicles

Fitment is sourced from official parts catalogues, listed per catalogue market.

Location in exploded diagrams

Other parts on this diagram — DRIVEN PULLEY

• 961406001300 — Sym CRUiSYM 300 E5 RADIAL BALL BRG. 6001LUC3
• 9430108140 — Sym CRUiSYM 300 E5 DOWEL PIN 8*14
• 934010503508 — Sym CRUiSYM 300 E5 WASHER BOLT 5*35
• 934010501600 — Sym CRUiSYM 300 E5 WASHER BOLT 5*16
• 91202HMA000 — Sym CRUiSYM 300 E5 OIL SEAL
• 90401KJ9000 — Sym CRUiSYM 300 E5 THRUST WASHER 14X28X2
• 90201KR8751M1 — Sym CRUiSYM 300 E5 FLANGE NUT 14MM
• 90157F3G000 — Sym CRUiSYM 300 E5 SOCKET BOLT 8X20
• 31120LM7000 — Sym CRUiSYM 300 E5 STATOR COMP
• 31110LM7000 — Sym CRUiSYM 300 E5 FLYWHEEL COMP
• 28110HMA000 — Sym CRUiSYM 300 E5 STARTING CLUTCH GEAR COMP
