Verified fitment — 7 vehicles
Fitment is sourced from official parts catalogues, listed per catalogue market.
Location in exploded diagrams
Other parts on this diagram — 支架
- #1 42100C26L00W000 — STAND, CENTER
- #2 42211C39J00W000 — SHAFT, CENTER STAND
- #4 04111C3020AW000 — PIN
- #5 42251C32G00W000 — BOLT, CENTER STAND SPRING
- #6 09443C17026W000 — SPRING
- #7 42272C09J00W000 — CUSHION, CENTER STAND
- #8 42310C45L00W000 — STAND, PROP
- #9 42241-33G00-000 — SPRING, PROP STAND
- #10 42334C39J00W000 — SPACER, PROP STAND
- #11 42411C39J00W000 — BOLT, PROP STAND
- #12 08319C3108AW000 — NUT
