2022 CF MOTO CF650-7FOEM parts & exploded diagrams
EE market478 parts15 groups12+ diagrams
Vehicle #2032
- CC
- —
- HP
- —
- 年款
- —
Exploded diagrams — 2022 CF MOTO CF650-7F
Part numbers on the 2022 CF MOTO CF650-7F
Each number has a dedicated cross-reference & fitment page.
- 6NTV-150100-C200 — MAIN CABLE
- 6NTV-150100-C202 — MAIN CABLE
- 30006-060012870 — BOLTM6x12
- 0010-080013-0010 — BOLT M6x22
- 6NQ0-000100-10000 — GEARSHIFT ROD ASSY
- 6NQ0-000100-1BP00 — GEARSHIFT ROD ASSY MAUD SPIRIT BLACK
- 6NQ0-000101-1BP01 — GEARSHIFT ROD MAUD SPIRIT BLACK
- 6NQ0-000101-1BB00 — GEARSHIFT ROD PLASTIC POWDER
- 6NQ0-000101-1BB01 — GEARSHIFT ROD PLASTIC POWDER
- 0700-065404 — FOOT PEDAL RUBBER SLEEVE
- 30001-102098110 — BOLT M10x1.25x98
- 30006-080020810 — BOLT
- A000-000210 — RH BRACKET, ENGINE
- A000-000201 — BUSHING, ENGINE
- 30203-102110 — NUT M10x1.25
- 6NTA-000220 — LH BRACKET, ENGINE
- 30001-102085110 — BOLT M10x1.25x85
- 6NQ0-000102 — GUARD, SMALL SPROCKET
- A000-000103 — AIR DEFLECTOR
- 5020-040018 — FRONT STORAGE BOX SEAL STRAP
- 6NTA-000201 — LH MOUNT SLEEVE, ENGINE
- A000-040702 — INNER HEX SCREW M6x12
- 6NQV-011000-B100-M1 — LOCK KIT
- 6NQV-011000-B101-M1 — LOCK KIT
- 30110-421130010 — SELF-TAPPING SCREW
- 30102-060020810 — SCREW
- A000-010400 — CABLE, FRONT SEAT
- 6KMV-011020-B000 — BLANK KEY
- 6KMV-011020-B001 — KEY
- 0700-022012 — GASKET, EXHAUST PIPE
- 8010-020001 — NUT M8, MUFFLER JOINT
- 6NTV-021100-C001 — EXHAUST PIPE ASSY
- 6NQV-021001-B000 — SEAL SLEEVE 1, GRAPHITE
- A000-020600 — CLAMP 2
- 6NTV-021200-C002 — MUFFLER ASSY
- A000-020005 — BUSHING
- A000-020004 — DAMPER, MUFFLER
- 30204-080810 — LOCK NUT
- A000-020006 — SHAFT, MUFFLER
- 6NQ#-020001-2602 — GUARD, MUFFLER
- 6NQV-031000-B100-01-0BY00 — FRAME ASSY NANO BLACK
- 6NQ0-030030 — LH BRACKET, LOWER DEFLECTOR
- 6NQ0-030040 — BRACKET, LOWER DEFLECTOR(RH)
- 6NQ#-030190-6000-0BY00 — SIDE STAND ASSY NANO BLACK
- A000-030006 — SIDE BRACKET BOLT
- A000-030210 — SIDE STAND SPRING ASSY
- A000-030004 — SPRING COLLAR, SIDE STAND
- 30208-102810 — NUT
- 8080-040064 — FRONT FENDER DAMPER
- A000-040302 — RUBBER DAMPER
- 30102-060016810 — SCREW
- A000-030120 — BRACKET, REGULATOR
- A000-030130 — BRACKET 2, REGULATOR
- 5020-031001 — RUBBER SLEEVE, FRONT LICENSE BRACKET
- 5020-031002 — RUBBER SLEEVE LINER
- 6NQ0-030100-0BB00 — BRACKET, REAR FENDER PLASTIC POWDER
- 6KJ0-030601-0BB0 — SUPPORT PLATE, REAR LICENCE
- 6KM#-030110-8000-0BB00 — BRACKET, REAR LICENSE (MAUD SPIRIT BLACK)
- 6NQ0-130216 — CUSHION RUBBER WAHSER
- 30105-050016410 — SCREW M5X16
