2026 CF MOTO NK 450NKOEM parts & exploded diagrams
AU market812 parts16 groups12+ diagrams
Vehicle #1925
- CC
- —
- HP
- —
- 年款
- —
Parts by assembly group
Exploded diagrams
Part numbers on this vehicle
Each number has a dedicated cross-reference & fitment page.
- 0SQV-011102-1000 — OIL NOZZLE
- 0SQV-011104-1000 — FILLER SEAL RING
- 0010-090005-0010 — BOLT M6x16
- 0SQV-011105-1000 — LH BEARING PLATE
- 0SQV-01FZ01-1003-0BP00 — CRANKCASE ASSY
- 0SQV-012400-1000 — OIL PRESSURE SWITCH
- 0SQV-011107-1000 — O-RING
- 0SQV-011108-1000 — FORK SHAFT COVER
- 30403-01400 — NEEDLE BEARING
- 1F30-011600-10000 — OIL SEAL
- 30403-02500 — NEEDLE BEARING
- 0SQV-011103-1000 — RESTRICTION PLUG
- 0SQV-011106-1000 — RH BEARING PLATE
- 30406-00401 — ROLLER NEEDLE P4x7.8
- 0SQV-012700-1000 — BOLT ASSY
- 0SQV-012200-1000 — BOLT ASSY
- 0SQV-011004-1000 — BEARING RETAINER
- 0SQV-011003-1000 — BEARING RETAINER
- 30410-01000 — ROLLER 10x14
- 0SQV-012003-1000 — BOLT
- 0700-012105-00001 — PLUG, MAIN OIL RAIL
- 0700-012106-00002 — OIL FILTER BOLT
- 0SQV-012002-1000 — BOLT
- 0SQV-012500-1000 — BOLT ASSY
- 0SQV-012600-1000 — BOLT ASSY
- 0SQV-012600-1001 — Bolt Assy M8X55
- 0SQV-010001-1000-M1 — COUNTERSHAFT OIL SEAL
- 0010-060012-0010 — BOLT M6x30
- 0010-021017-0010 — BOLT M6x25
- 0700-012201 — O-RING
- 0SQV-013100-1000-M1 — VIEWER, OIL LEVEL
- 0SQV-013001-1000 — RETAINER
- 30410-00800 — ROLLER
- 30403-01200 — BEARING
- 0010-080009 — OIL SEAL
- 0SQV-013005-1001-0D300 — RH SIDE COVER
- 0700-013008 — OIL FILLING PLUG
- 0110-013030 — O-RING
- 0SQV-014001-1000-0D300 — LH SIDE COVER
- 6WWV-030080-8000 — CLIP
- 01A0-012003 — O-RING
- 01A0-012002-0D300 — FILTER COVER
- 0DM0-011006 — O-RING
- 0DM0-014003 — VIEWING HOLE, TIMING INSPECTION
- 0SQV-015001-1001-0BP00 — OIL PAN
- 0010-021014 — WASHER 12
- 0NYV-073001-3000 — DRAIN BOLT Replacing: 0180-011500 - DRAIN BOLT MAGNETIC (M12X1.25)
- 0010-021019-0010 — BOLT M6x12
- 0SQV-021004-1000 — PRESS PLATE
- 0700-021003-00001 — CYLINDER HEAD COVER BOLT
- 0700-021200 — CYLINDER HEAD COVER BOLT SEAL RING
- 0SQV-021010-1001-0BP00 — CYLINDER HEAD COVER ASSY
- 0SQV-021100-1000 — LABYRINTH PRESS PLATE ASSY
- 0SQV-021002-1000 — CYLINDER HEAD COVER SEAL RING
- 0HU0-021002-00001 — GULP PIN
- 0SQV-170200-1000 — SPARK PLUG ASSY
- 0SQV-178000-1001 — IGNITION COIL
- 0SQV-021005-1000 — LABYRINTH COVER GASKET
- 0SQV-022105-1000 — BOLT
- 0SQV-022106-1001 — HEX FLANGE BOLT
